DELO HOUSE 3
6.6 m
18.6 m
7. Corridor
8. Bedroom
9. Bedroom
10. Bedroom
11. Entrance hall
12. Terrace
5 m²
11.5 m²
7.9 m²
7.9 m²
4.5 m²
20.6 m²
4.5 m
3.1 m
0
1
2
3
4
5
6
7
9
8
10
11
- 0,5 m
12
1. Living room
2. Kitchen
3. Toilet
4. Bathroom
5. Boiler room
6. Wardrobe

Usable floor area:
Built-up area:

Dimensions (L х W х H):
30.5 m²
10.7 m²
1.25 m²
2.4 m²
3.65 m²
2.3 m²

87.5 m²
132 m²

18.6 m х 6.6 m х 4.5 m

Serially-produced frame house total area of 87 m² with an open terrace.
The house is built on a site according to frame technology using pre-prepared elements. The lightweight structure is erected on any foundation. The house is heat-insulated for living in winter.

The space of the house is used with maximum efficiency. House contains two bedrooms with built-in wardrobes, a bathroom with a bath, a spacious entrance hall and a kitchen-living room.

The terrace can have any shape and size.
The layout can be mirrored in any direction, and the windows can be positioned depending on the cardinal points, the desired view and the access way.
The house has a simple, easy-to-build and reliable structure.

During construction, only high-quality, environmentally friendly materials are used. The house is designed taking into account the standard sizes of materials and almost no wasteleft during its construction. This optimizes its cost and saves natural resources.
DELO HOUSE 3
Serially-produced frame house total area of 87 m² with an open terrace.

The house is built on a site according to frame technology using pre-prepared elements. The lightweight structure is erected on any foundation. The house is heat-insulated for living in winter.
The space of the house is used with maximum efficiency. House contains two bedrooms with built-in wardrobes, a bathroom with a bath, a spacious entrance hall and a kitchen-living room.

The terrace can have any shape and size.
1. Living room: 30.5 m²
2. Kitchen: 10.7 m²
3. Toilet: 1.25 m²
4. Bathroom: 2.4 m²
5. Boiler room: 3.65 ²
6. Wardrobe: 2.3 m²
7. Corridor: 5 m²
8. Bedroom: 11.5 m²
9. Bedroom: 7.9 m²
10. Bedroom: 7.9 m²
11. Entrance hall: 4.5 m²
12. Terrace: 20.6 m²

Usable floor area: 87.5 m²
Built-up area: 132 m²

Dimensions (L х W х H): 18.6 m х 6.6 m х 4.5 m
The layout can be mirrored in any direction, and the windows can be positioned depending on the cardinal points, the desired view and the access way.

The house has a simple, easy-to-build and reliable structure.

During construction, only high-quality, environmentally friendly materials are used. The house is designed taking into account the standard sizes of materials and almost no wasteleft during its construction. This optimizes its cost and saves natural resources.
Price

House with finishing

Built-up area 108.6 m²
Usable floor area 87.5 m²
Terrace 20.6 m²
Dimensions (LхWхH) 18.6 m х 6.6 m х 4.5 m

Frame

External walls, partitions Planed kiln-dried board 146х46/ 96x46 mm

≈ 214 300 €

Rafters Planed kiln-dried board 146х46 mm
Heat insulation Rockwool Light Batts stone wool (or analogue from other manufacturers)
Floors - 200 mm, walls - 200 mm, ceiling - 200 mm
Noise insulation of interior walls Rockwool Light Batts stone wool
Wind and vapor barrier Delta-Dawi GP, Acrylic Tape

Outside finishing

Roof Profiled flooring MP-18 0.5 mm, corner elements, drain
Walls MDVP, softwood planken, oil
Terrace Larch deck board 120х28 mm
Floor lags: planed kiln-dried board 146х46 mm, screw piles

Interior finishing

Walls and ceiling Planken from softwood, plasterboard, acrylic varnish/ paint
Floor Terazzo tile 28 mm
Doors Light panel door

Glass fixing

Facade windows Energy-saving double-glazedwindows with thermal break
Entrance door Warm metal or wooden door with thermal break

Lighting

Interior lighting Surface mounted LED luminaires

Utility system

Water supply and sewage Water supply (metall-plastic pipe 16х2,0, AlcaPlast shower gulley, AlcaPlast Sadromodul toilet installation system AM101/1120 without bowl), electric boiler Protherm Skat (Ray) V14 14 кВт, three-waly velves FUGAS for SKAT boiler (11 and 13 versions) Protherm, remote control unit for Vaillant GSM-Climate ZONT H-1V eBUS boilers, floor mounted inderect water heater Stout 200 l, input unit with filter bypass
Electrical Concealed wiring, built-in electrical panel, switches
Ventilation Air supply valves, air removal by humidity and CO2 sensors
Heating Water underfloor heating 12 cm (collector with flow meters and thermostatic valves with 12 outputs, PE-RT EVOH 16х2,0 pipe with oxygen barrier, tubing panels 75х1231х831 mm, pump-mixing unit MVI 1, heating system pump Unipump UPС 25-60 130)

Furniture and plumbing

Kitchen and wardrobe Chipboard Egger

≈ 35 700 €

Refrigerator
Washer
Tap
Stove
Lavatory basin
Sink
Shower
Washing machine
Sofa Delo Design
Tables Delo Design, Kroogster and Yo models
Chairs Delo Design, Tu and Yo models
Bed Solid pine, water-based varnish
Matress 160х200 cm
Blanket 200х200 cm
Pillows 50x70 cm
Linens Delo Design
Tablware Delo Design

Production time

4 months

Total cost

≈ 250 000 €

Prices are valid as of June 24, 2022
The price does NOT include:

Foundation

The cost of the foundation depends on the location, the type of soil, the length of the piles, the need to remove stones, etc. It is recommended to take a soil sample and conduct inspection
Concrete slab

Wastewater treatment station

Zorde-4
(for 2-5 people)
Erection: excavation, digging, submersion of the station, backfilling of the central heating station (ratio of cement to sand 1/4, 1/3) connection of electrics, (100 km from the pumping equipment, city) welding of branch piping, inspection and laying of pipes up to 10m, lead -into the house
Kolo Vesi
premium station
Kolo Vesi 3 (for 2 people)
Kolo Vesi 5 (for 4-5 people)

Terrace

20 m2, 28 mm larch decking, piled metal foundation

Wood burning fireplace

Prerequisites for building a house:
(compliance is monitored by the customer independently and is not included in the price)

  • Utility system available on the site, connected to the construction site: electricity, sewage and water supply
  • Ready foundation
  • Access roads to the construction site corresponding to the dimensions of transport
